Analog IC Design Lab Report
Four lab exercises for my Analog IC Design course — CMOS current mirrors, an OTA redesigned to a gain/bandwidth/offset spec, that same amplifier stabilized from a marginal 25° to 68.5° of phase margin inside a capacitive-feedback loop, and a band-gap reference tuned flat to within 0.09% of target over temperature. Each hand-calculated first, then verified in simulation.
View project →
